Building dynamic toggletips using anchored container queries

To add to the container query options that we already have (size queries, style queries, scroll-state queries), as well as the container query range syntax and many upgrades to all of the above, we can now use anchored container queries from Chrome 143.

Chrome’s announcement post demonstrates how, if we were using anchor positioning, we could use anchored container queries to query the currently active fallback position (if any). They’ve provided a little demo in the post where a toggletip caret is anchored to the side of a toggletip, but if the toggletip needs to be anchored to a different side of the trigger due to lack of space, the caret is anchored to a different side as well. So in this case, anchored container queries are used to determine which position the toggletip is in, so that we can position the caret accordingly.

This is a pretty good use-case for anchored container queries, but also a great opportunity to look at how we might build toggletips in the (hopefully) near future. You’ll learn about popovers and anchor positioning, which are already baseline and will ensure that the toggletips at least work, as well as declarative anchors, ‘modern’ attr(), and corner-shape, progressive enhancements enchantments that provide a range of magical benefits.

Here’s what we’ll be making:

In Chrome you’ll see toggletip carets that flip to the appropriate side depending on the amount of space available, but in other web browsers you’ll get the toggletips without carets.

Let’s get into it!

Setting up the popover and anchor associations

We’ll be using popovers to mark up the toggletips, as that’s the semantic way to do so these days, but before we begin it’s worth mentioning that they’re implicitly anchored. However, since you might want to use anchored container queries without popovers, I’ll show you how to set up anchor associations anyway.

To set up the popover and anchor associations in a declarative but progressively enhanced way, we’ll need the following HTML markup:

<div anchor="leftButton" id="--leftPopover" popover>Toggletip</div>
<div anchor="centerButton" id="--centerPopover" popover>Toggletip</div>
<div anchor="rightButton" id="--rightPopover" popover>Toggletip</div>

<button id="leftButton" popovertarget="--leftPopover">Button</button>
<button id="centerButton" popovertarget="--centerPopover">Button</button>
<button id="rightButton" popovertarget="--rightPopover">Button</button>

The most familiar part of this is probably the popover markup. We’ve given the toggletips the popover attribute, and then an id so that each trigger can reference a popover using the popovertarget attribute. The strange part is that we’ve used custom-ident values (e.g., --leftPopover), but I’ll explain why shortly. That’s the popover functionality set up.

For the anchor positioning we’ve also given ids to the triggers, and then referenced them from anchor attributes set on the toggletips. These values don’t have to be custom idents.

However, for web browsers that don’t support the anchor attribute, we’ll need to use CSS instead, and there’s a shorter and a longer way to do that depending on whether or not modern attr() is supported.

The shorter, modern attr() way:

/* Modern attr() supported */
@supports (x: attr(x type(*))) {
  button {
    /* Reuse the name from popovertarget */
    anchor-name: attr(popovertarget type(<custom-ident>));
  }

  [popover] {
    /* Anchor to the relevant button */
    position-anchor: attr(id type(<custom-ident>));
  }
}

Basically, if modern attr() is supported, we reuse the popovertarget values of the buttons as anchor names while making it clear that we want to parse them as custom idents. After that, we match the id values of the popovers to said anchors, thus setting up the anchor positioning associations. The anchor-name and position-anchor CSS properties only accept custom idents (e.g. --leftPopover), so that’s why we’re making a big fuss about them.

Next, if modern attr() isn’t supported, name each anchor manually:

/* Modern attr() not supported */
@supports not (x: attr(x type(*))) {
  /* Assign anchor name */
  #leftButton {
    anchor-name: --leftButton;
  }

  /* Anchor to button */
  #leftPopover {
    position-anchor: --leftButton;
  }

  /* And so on... */
  #centerButton {
    anchor-name: --centerButton;
  }

  #centerPopover {
    position-anchor: --centerButton;
  }

  /* And so on... */
  #rightButton {
    anchor-name: --rightButton;
  }

  #rightPopover {
    position-anchor: --rightButton;
  }
}

Once modern attr() is Baseline widely available, we can delete this block, and then once the anchor attribute is Baseline widely available, we can delete all of this CSS. You won’t even need to use custom-ident values, so --leftPopover can become leftPopover, for example.

Note: if we’d rather that the toggletips be triggered on :hover (making them tooltips instead of toggletips), we can swap popovertarget for interestfor, but note that interest invokers are only supported in Chrome 142 and above. Keep them in mind for the future!

Advert

Aligning and styling the toggletips

Like last time, I’ll drop the code right here so you can skim through it before we look at it line-by-line:

[popover] {
  position: fixed;

  /* Align to right/implied center */
  position-area: right;

  /* If no space, flip to other inline side */
  position-try: flip-inline;

  /*
    1rem of spacing between the button and
    toggletip that also flips side accordingly
  */
  margin-inline-start: 1rem;

  /* Anchor toggletip caret to this */
  anchor-name: --toggletip;

  /* Used to query this container’s fallbacks */
  container-type: anchored;

  /* Scooped corners, if supported */
  @supports (corner-shape: squircle) {
    border-radius: 3rem;
    corner-shape: squircle;
  }

  /* Normal corners, if not supported */
  @supports not (corner-shape: squircle) {
    border-radius: 1rem;
  }
}

First, we must declare position: fixed on the anchored element (in this case though, popovers already have it).

Next, we need to position the toggletip relative to the button (let’s say the center-right) using the position-area property. Now, you might think that position-area: center right is the correct declaration here, but here’s what that actually does:

As you can see, it’s overflowing the center-right tile, which is wrong but forgiving, since web browsers declare align-self: anchor-center under the hood to make it work anyway. This is declared on what’s called the Inset-Modified Containing Block (IMCB), which again is the center-right tile.

However, for reasons unknown, web browsers aren’t so forgiving when a fallback position is activated. The trick is to use position-area: right instead. By omiting the center keyword, it resolves to position-area: span-all right, which does this:

Now the toggletip does fit into the tile (IMCB). And again, it’s vertically aligned within the center of it due to align-self: anchor-center.

We can safely use position-try: flip-inline, which turns right into left whenever the toggletip overflows the viewport. Later on, anchored container queries will query whether this is happening or not.

After that, margin-inline-start: 1rem adds 1rem of spacing between the button and the toggletip at the start of the inline axis, which also flips accordingly.

Advert

anchor-name: --toggletip turns the popovers into anchors so that we can create toggletip carets and anchor them to said popovers. Normally this’d be a naming collision waiting to happen (because three different popovers are now called --toggletip, right?), but the toggletip carets will be nested inside the popovers, so they’re somewhat scoped.

And remember, we’ll be flipping the toggletip’s caret to the opposite side whenever the toggletip is flipped, and that’s what container-type: anchored is for — it’s a totally new type of container and we’ll be querying it’s fallback position to determine the correct side.

One more thing, though…

If corner-shape: squircle is supported (@supports (corner-shape: squircle)), then we use it with border-radius: 3rem to create corners that aren’t quite rounded but aren’t quite square either. If it’s not supported then we just use border-radius: 1rem. This is optional of course, but corner-shape will play a bigger role when we use it again in a moment:

/* Scooped corners, if supported */
@supports (corner-shape: squircle) {
	border-radius: 3rem;
	corner-shape: squircle;
}

/* Normal corners, if not supported */
@supports not (corner-shape: squircle) {
	border-radius: 1rem;
}

Creating and positioning the toggletip’s caret

Similar to how we anchored the toggletips to the buttons, the following code anchors the toggletip carets to the toggletips:

[popover] {
	/* Previous section code */

  /* Toggletip caret */
  &::after {
    /*
      Only create carets if anchored
      container queries are supported
    */
    @supports (container-type: anchored) {
      /* Create caret */
      content: "";

      /* Anchor to toggletip */
      position: fixed;
      position-anchor: --toggletip;

      /* Scooped carets, if supported */
      @supports (corner-shape: scoop) {
        height: 1rem;
        aspect-ratio: 1/2;
        corner-shape: scoop;
        background: inherit;
      }

      /* Normal carets, if not supported */
      @supports not (corner-shape: scoop) {
        /* Hack to create a triangle */
        width: 0;
        height: 0;
        border-top: 0.5rem solid transparent;
        border-bottom: 0.5rem solid transparent;
      }

      /* If no fallback */
      @container anchored(fallback: none) {
        /* Position caret on the left */
        position-area: left;

        /* Needed for scooped carets */
        @supports (corner-shape: scoop) {
          border-top-left-radius: 100% 50%;
          border-bottom-left-radius: 100% 50%;
        }

        /* Needed for normal carets */
        @supports not (corner-shape: scoop) {
          /* Part of the triangle hack */
          border-right: 0.5rem solid var(--toggletip-color);
        }
      }

      /* If flip-inline fallback triggered */
      @container anchored(fallback: flip-inline) {
        position-area: right;

        @supports (corner-shape: scoop) {
          border-top-right-radius: 100% 50%;
          border-bottom-right-radius: 100% 50%;
        }

        @supports not (corner-shape: scoop) {
          border-left: 0.5rem solid var(--toggletip-color);
        }
      }
    }
  }
}

First of all, the toggletip carets are CSS-generated using the ::after pseudo-element:

[popover] {
  &::after {
    /* Toggletip caret */
	}
}

Then, within that, we need to see if the web browser supports anchored container queries (if not, the toggletip carets simply aren’t generated, although the toggletips will still work):

[popover] {
  &::after {
		@supports (container-type: anchored) {
	    /*
	      Only create carets if anchored
	      container queries are supported
	    */
		}
	}
}

Within that, content: "" generates the toggletip carets (or, rather, it generates a pseudo-element with no content that we’ll style into carets).

position: fixed and position-anchor: --toggletip anchors them to the toggletips.

After that, we again leverage corner-shape to create scooped toggletips. Or, if corner-shape isn’t supported, then we use the classic border trick to create triangle-shaped carets.

We also — finally — implement those anchored container queries to position the carets to the correct side of the toggletips. When a fallback isn’t active, @container anchored(fallback: none) will match, but when a fallback is active, @container anchored(fallback: flip-inline) will match. The value of fallback simply needs to match a value of position-try:

/* Scooped carets, if supported */
@supports (corner-shape: scoop) {
	height: 1rem;
	aspect-ratio: 1/2;
	corner-shape: scoop; /* (Border radius is set later) */
	background: inherit;
}

/* Normal carets, if not */
@supports not (corner-shape: scoop) {
	/* Hack to create a triangle */
	width: 0;
	height: 0;
	border-block: 0.5rem solid transparent; /* (Side is set later) */
}

/* If no fallback */
@container anchored(fallback: none) {
	/* Position caret on the left */
	position-area: left;

	/* Left border radii for scooped carets */
	@supports (corner-shape: scoop) {
		border-top-left-radius: 100% 50%;
		border-bottom-left-radius: 100% 50%;
	}

	/* ‘Left’ border for normal carets */
	@supports not (corner-shape: scoop) {
		border-right: 0.5rem solid var(--toggletip-color);
	}
}

/* If flip-inline fallback triggered */
@container anchored(fallback: flip-inline) {
	position-area: right;

	/* Right border radii for scooped carets */
	@supports (corner-shape: scoop) {
		border-top-right-radius: 100% 50%;
		border-bottom-right-radius: 100% 50%;
	}

	/* ‘Right’ border for normal carets */
	@supports not (corner-shape: scoop) {
		border-left: 0.5rem solid var(--toggletip-color);
	}
}

As a reminder, here’s the final demo:

Wrapping up

Container queries are evolving beautifully, especially with the newest addition, anchored container queries. And, thanks to other modern CSS features such as the anchor attribute, ‘modern’ attr(), corner-shape, and even interest invokers, we can include all kinds of progressive enhancements to create some really awesome — in this case — toggletips.

If you want to go ahead and implement this (full code in the demo), you totally can. If something isn’t supported it’ll simply revert to something that is, and then as new features become baseline, you can very easily remove the code that’s no longer needed.
