A Front-end developer’s guide to the hybrid mobile app development landscape

Just as with every aspect of my life, I find it hard to identify my software development skills. At my heart, I am a developer, though I spent way too much time as a high school senior fretting about whether or not I’d become an engineer. On paper, my job title has been product owner for almost the same amount of time as engineer/developer, but I was still writing code and reviewing PRs. Then comes the question of what kind of developer am I? Web developer? Mobile developer? Front-end? Full-stack? So many titles, but not a single one that fully encompasses my experience. I can tell you one thing that I’m not is a back-end developer 😆

All that said, for the purposes of this article, I’m a front-end web developer who has spent their 7 year career building a product for testing accessibility of mobile apps. I’d like to give you — a front-end web developer, who may not have mobile experience — a quick run-through to the mobile apps built with web technologies landscape.

What is a hybrid mobile app?

As a front-end web developer, we’re used to our HTML content being rendered in the browser whether it’s being generated by a framework like React or Vue, or being served from an HTML file.

The mobile app world is a quite different story where the rendered content doesn’t follow agreed upon and maintained guidance, like web standards. For example, Apple and Google completely govern their own native tech stacks for building iOS and Android apps respectively. Those tech stacks create elements on the screen called Views. Then there’s the 3rd party cross-platform frameworks such as React Native, .NET MAUI (previously Xamarin), Flutter. These all allow you to build both an Android and iOS app, and sometimes a web and/or desktop app, from a single code base, but they each do that process a bit differently to each other.

React Native and .NET MAUI generate Views that mimic or are very similar to native mobile Views. They are designed to use technologies familiar to React and .NET developers: TypeScript/JavaScript with CSS and C# with XAML. Flutter is in it’s own league because it uses Dart to build Widgets that are rendered by it’s own graphics engine, bypassing the concept of native Views entirely.

While all these frameworks are often referred to in discussions of hybrid mobile apps, I prefer to distinguish them as cross-platform or code-once frameworks and reserve hybrid to specifically describe the subset of apps which present a blend of web and mobile content.

We’ll define a hybrid mobile app as follows: “A mobile app which primarily features HTML content rendered in WebViews alongside some native mobile content or functionality”

A WebView is a native mobile View which acts as an embedded web browser component to render HTML content inside of it instead of native controls like sliders or buttons. The mobile browser apps such as Safari and Chrome utilize a WebView as the main component with the addition of peripherals like the URL bar and back button. That’s a route to web developers to feel empowered rather than hindered.

The cross-platform framework names I haven’t mentioned yet are by this definition, hybrid app development frameworks: Ionic, Capacitor, Cordova/PhoneGap. It’s a bit complicated to untangle what each framework is and does, so we’ll dive into that in the next section.

Advert

Hybrid App Development Frameworks

Let’s start by talking about Apache Cordova/Adobe PhoneGap, since it’s the original hybrid framework, created back in 2009. Here’s the overview statement on the Cordova documentation site:

Apache Cordova is an open-source mobile development framework. It allows you to use standard web technologies - HTML5, CSS3, and JavaScript for cross-platform development. Applications execute within wrappers targeted to each platform, and rely on standards-compliant API bindings to access each device’s capabilities such as sensors, data, network status, etc.

There’s some history with the project being acquired by Adobe, including in an offering called PhoneGap, but that was discontinued in 2020. Cordova is still alive and actively maintained, but you may see references to PhoneGap while looking for hybrid app development topics.

Cordova isn’t a UI framework, but rather a runtime environment for your web app on a mobile device. This means you could take an existing web app that you built with your favorite front-end tools and package it up to render inside a WebView in both an iOS and Android app. Now there’s quite a lot of reasons why you wouldn’t want to to that, but let’s cover the other runtime frameworks first.

Capacitor is a newer option for a hybrid framework to ship your web content wrapped in a mobile app, developed in 2018 as a modern alternative to Cordova/PhoneGap. The intro on the Capacitor docs site reads:

Capacitor is a cross-platform native runtime that makes it easy to build performant mobile applications that run natively on iOS, Android, and more using modern web tooling. Representing the next evolution of Hybrid apps, Capacitor creates Web Native apps, providing a modern native container approach for teams who want to build web-first without sacrificing full access to native SDKs when they need it.

What separates Capacitor from Cordova is that it’s built and maintained by the Ionic framework team. While the former are both native runtime frameworks, Ionic is actually a front-end UI framework for hybrid apps. Ionic can be used with both Cordova and Capacitor, but Capacitor is designed specifically to work in conjunction with Ionic. Here’s the introduction on the Ionic docs site:

Ionic is an open source UI toolkit for building performant, high-quality mobile apps using web technologies — HTML, CSS, and JavaScript — with integrations for popular frameworks like Angular, React, and Vue.

Now we’re finally in the front-end developer’s domain! Before we dig into it too much, let’s go over some important design concepts for hybrid apps.

Designing a Hybrid App

Like I said earlier, you can use either Capacitor or Cordova, to wrap your existing web front-end into a WebView inside a mobile app, but there are some considerations to make since content built for the web is structured quite differently than content built for mobile.

For example, a common pattern in web apps is a single page with lot of content that can be scrolled to or jumped to with links/landmarks. Whereas, in a mobile app, content is often better presented in small chunks with navigation through a flow of multiple screens. Mobile app user experience is built around the fact that the content is displayed in a small viewport, but the web was originally built for desktop and adapted to suite mobile devices as their browser became more and more capable.

I’ve spoke with folks in the industry that claim most users can’t tell whether an app is presenting native content or a WebView, but I find that hard to believe. Maybe I’m biased because I know too much about both, but it says a lot if a user downloads your app instead of visiting your website since there’s a much higher barrier to entry. They likely took the extra effort to open the App Store or Play Store and remember or find their account password to install your app because they want a native mobile experience. One thing I can confidently say is that a screen reader user will definitely know the difference since it will literally announce WebView when they hit one, and the landmarks are different, like the fact that Android only has 1 level of heading compared to the 6 levels in HTML <h1>-<h6>.

So all that said, how do you build a stellar hybrid app user experience? By using the concepts of responsive and mobile-first web design of course!

Figma has a wonderful article which covers the topic focusing on websites, but can be applied to hybrid apps as well:

“Mobile-first website design flips the traditional Web development approach. Instead of starting with a desktop layout and scaling down, you begin with a mobile website design. This approach prioritizes smaller screens, slower Internet connections, and the needs of on-the-go users.”

Another layer to mobile-first design is that Android and iOS each have a look and feel uniquely branded to Google and Apple. We’ve established that the web and mobile ecosystems are very different, but iOS and Android are almost just as different too. So you’re faced with some choices: design 2 experiences, pick iOS or Android and ship it to the other platform anyways, or roll your own that ideally caters to both. Trust me, I’ve seen it all, and my least favorite is an Android styled app shipped to iOS

While companies/brands love the idea of a consistent experience across platforms, users prefer your app to look behave like the rest on their device do. A lot of factors go into choosing a design pattern for an app such as target audience, development resource capacity, etc, so let’s set that aside and finally dig into building the bits

Building a Hybrid app Front-end

I want to bring us back to Ionic because its UI component library allowing front-end developers to build seamless experiences for both iOS and Android from a single codebase using technologies you know and love. It’s full of mobile-first components which render on iOS matching Apple’s aesthetics and on Android matching Material Design, Google’s open-source design system. These components are available in Angular, React, Vue, and plain ole JavaScript with beautiful interactive demos on the documentation site.

Let’s take a closer look at a Toggle component which is commonly used in the settings of a mobile app. In React, you import the IonToggle from Ionic’s library and use it just like you would any component for a web-first app.

import React from 'react';
import { IonToggle } from '@ionic/react';

function Example() {
  return (
    <>
      <IonToggle>Default Toggle</IonToggle>
      <IonToggle checked={true}>Checked Toggle</IonToggle>
      <IonToggle disabled={true}>Disabled Toggle</IonToggle>
      <IonToggle checked={true} disabled={true}>
        Disabled Checked Toggle
      </IonToggle>
    </>
  );
}
export default Example;

On iOS, you’ll get 4 toggles in Apple’s well known style.

For Android, the recognisable material design elements are used.

All of the Ionic components can be styled with CSS custom properties and standard CSS, so you can achieve that consistent experience across platforms by modifying the iOS and Android styles slightly or make them match exactly.

Accessibility

As digital accessibility advocate, I can’t write an article without touching on the topic. I think of accessibility in 2 realms: compliance and user experience.

The realm of compliance focuses on building digital content that adheres to the Web Content Accessibility Guidelines (WCAG). These are the guidelines which legislature around the world reference, and large enterprises strive to meet. There isn’t a similar de facto standard for mobile app accessibility despite the immense difference in how content is rendered, but instead, there’s only adaptations and interpretations of WCAG for mobile.

On the other hand, Apple and Google put emphasis on accessibility through the user experience of the iOS and Android ecosystems. There’s Apple’s Human Interface Guidelines with a foundations section dedicated to accessibility, and the Android Developer guide on accessibility.

There’s no straightforward way to make a perfectly accessible app today, but that’s ok! Just as with most things in life, it’s about finding the right balance. On the compliance side, that WebView inside a mobile app is rendering HTML, so WCAG criteria can be directly applied, so there’s certainly advantages for hybrid apps in that regard. However, accessibility compliance doesn’t always equate to a high quality user experience, which is where the advice from Apple and Google come into play.

Wrapping up

While the world of mobile apps can be intimidating to a front-end web developer, it’s certainly worth exploring, even to be aware of the landscape for if you find yourself in a project in the future.

With that in mind, I hope this article is a useful introduction and shows that you don’t have to step completely out of your comfort zone thanks to the concept of hybrid mobile apps, providing a very familiar experience. It makes them a useful jumping off point!
